RFID Pallet Tag for Wood and Plastic Pallet Tracking and Identification

RFID Tag Pallet Tracking Description:

The RFID pallet tag is an exceptional device for monitoring a pallet’s location, whether crafted from wood or plastic. Housed in a durable ABS casing, this token tag is impervious to water. Furnished with a 3M adhesive, these tags adhere firmly to pallet objects, enabling the sorting, tracking, and identification of any item they are affixed to. They provide unparalleled visibility of the product on the pallet and its precise position within the warehouse. This pallet tag ensures that the correct products reach your production lines in the proper quantities, adhering to stringent quality assurance standards. Its compact design allows it to attach seamlessly to the pallet, reducing the risk of collision or wear during transportation. It's an exemplary practice for warehouse operations.

RFID Pallet Tracking Working Flow:

1. Affix the RFID pallet tag to the pallet; RFID readers are stationed at the entrance and exit points of the warehouse. As the pallet passes these readers, the tag information is captured.

2. The RFID reader autonomously reads the tag details and uploads them to the system as goods move in and out of the warehouse.

3. Pallet classification ensures that the information and labels on the pallet are accurately matched.

4. The RFID reader mounted on the forklift can automatically discern pallet classifications, placing goods in the correct location when shelved or transferred.

5. The warehouse keeper can use a handheld reader to identify the location, inventory, and classification of goods.

RFID Pallet Tag Specifications:

• Size: Dia20mm, Dia30mm, Dia39mm

• Chip: TK4100/Mifare 1K/I-Code SLI/Ntag213/Ntag215/Ntag216

• Frequency: 125KHz/13.56MHz

• Material: ABS

• Reading Range: 0~10CM (reader-dependent)

• Temperature: -20 ~ +60C

• Feature: Waterproof, Shockproof

• Color: Black, White, Orange, etc.

• Customization: Logo and number printing

• Installation: Adhesive with 3M sticker or screw

RFID Pallet Tracking Applications:

• Pallet tracking

• Property tracking

• Warehouse management

• Patrol
